    Heavy Duty Thomas Engineering Truss 50 * 3 Millimeter Main Tube 2 Years Warranty

    Ask Lasest Price
    Brand Name : Meile
    Model Number : ML-133
    Certification : CE, SGS
    Price : negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100000m/month
    Delivery Time : 7-10 work days
    • Product Details
    • Company Profile

    Heavy Duty Thomas Engineering Truss 50 * 3 Millimeter Main Tube 2 Years Warranty

    Aluminum Truss Frame Aluminum Tomcat Truss Thomas Truss 300mm * 300mm


    Company Introduction


    Establised in 2010, Guangzhou Meile Exhibition Equipment Co.,ltd has been one of leading manufacturer of performance and exhibition equipment in China. Main product including aluminum truss, aluminum stage and aluminum big wedding party tent. They are produced according to European standard EN13814 and welding EN1090.


    We persist in quality first, it drives us to develop advanced technology and establish a strict quality control system to meet clients’ requirements, we guarantee every material we used are picked up carefully and fully tested.


    Thomas Truss Specifications



    SectionMain TubeMax. SpanLoading capabilityCategory
    200*200mmφ30*2mm10m75kgLight Duty Truss
    300*300mmφ50*3mm12m350kg
    350*350mmφ50*3mm13m400kg
    400*400mmφ50*3mm14m500kgMiddle Duty Truss
    450*450mmφ50*3mm15m550kg
    400*600mmφ50*3mm16m600kg
    500*600mmφ50*3mm18m650kgHeavy Duty Truss
    520*760mmφ50*4mm20m1000kg
    600*760mmφ50*4mm24m1500kg

    • 1. Truss materials: Hard pressed extruded aluminium alloy 6061/T6 or 6082T6.

    • 2. Specifications: 300*300mm,

    • 3. Length of each piece of truss: 1M/2M/3M/4M.

    • 4. Main tube: 50mm*3mm.

    • 5. Brace tube: 30mm*2mm

    • 6. Weight loading capability: 350kg/square meter according to the truss size.

    • 7. Features: light weight, heavy duty

    • 8. Application: it is widely used for outdoor indoor activities, such as exhibition, promotion, concert, wedding, party, festival ceremony etc.

    Heavy Duty Thomas Engineering Truss 50 * 3 Millimeter Main Tube 2 Years Warranty


    Warranty


    Life-time warranty. Any problem caused by our party within 2 years from the date of shipment, we will provide free spare parts for the repairment. After 2 year, we can provide the spare parts, but the user should pay for the related cost, including spare parts cost and delivery cost etc.
