    Hexagonal Aluminum Pagoda Tent Double Pvc Coated Polyester Apply To Exhibition

    Ask Lasest Price
    Brand Name : Meile
    Model Number : ML-012
    Certification : CE, SGS
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100sets/month
    Delivery Time : 7 work days
    • Product Details
    • Company Profile

    Hexagonal Aluminum Pagoda Tent Double Pvc Coated Polyester Apply To Exhibition

    Aluminum Pagoda Tent Dia.8m Exhibition Hexagonal Tent Aluminum Frame

    Description


    1. Aluminum frame with pvc cover,
    2. Dia.8m, total area is about 65sqm, it is suitable for 50-60 person.
    3. You could extend the whole space according to combine many such small sets together.
    4. The guarantee of the tent frame material is 15 years, of the cover material is 5 years.



    Hexagonal tent series size

    Main frame profileSizeWidthEave heightRidge heightTotal Area
    84x48x2.5mmDia.6m3m3m3.9m23.4SQM
    Dia.8m4m3m4.1m42SQM
    Dia.10m5m3m4.5m65SQM



    Specifications


    Size8m diameter
    Sidewall height3m
    Ridge height4.1m
    Frame mateiralAluminum alloy 6061T6, Main frame material: 84*48*3.5mm
    Cover mateiraldoulbe pvc coated polyester, 850g/sqm for roof cover, 650g/sqm for sidewall sheet. It is high quality at waterproof, flame retardant to DIN4102 B1,M2,U V resistant.
    Connector materialHot-dip galvanized steel, tough, durable and anti-rust
    Wind resisting capability100km/h
    Wind loading capability0.3km/square meter
    Temperature reisistance-30---+70 centigrade
    Tent features1. Easy to set up, dismantle and transport
    2. Logo printing is available
    3. All the sidewalls can be put on or take off, opened or closed accroding to your different occasion.
    ApplicationIt is wdely used in outdoor wedding, party, performance, exhibition, promotion,,outdoor trade fair, celebration, sports event, military solution, temporary warehouse and workshop and so on.



    Accessories
    1. clear pvc windows, or clear pvc sidewall
    2. roof lining and sidewall curtain, any color is available
    3. plywood floor (Aluminum frame with 18mm thickness platform)
    4. glass wall or glass door ( Aluinum frame with 6mm thickness toughened glass)
    5. ABS wall ( hard plastic)
    6. Air conditioning system (3p or 5p and different brand)
    7. Ground anchor (0.5/1m per piece), loading plate or expansive screw
    8. Rain gutter (pvc material)



    Remark


    We could produce many tent kinds, such as ridge tent, arch tent, polygonal tent, glass tent, transparet tent, small pagoda and customized shape tent etc. Welcome your inquiry sincerely if you have any interests about it.
